Portfolio
Drawings, as delivered
Every sheet here was drafted for a paying client between 2021 and 2026. Names, addresses, parcel numbers and logos are removed from the drawings themselves. Open any sheet for the brief, what we delivered and how long it took.
Elementary school as-builtFull first floor plan, scaled from scanned PDFs K-12 · New England3 schools in 4 days
Elementary school as-builtGround floor plan on a sheet layout K-12 · New England1 gap round
School ground and basement plansExisting conditions, every level K-12 · New EnglandDelivered with the set
Remodel survey draftingLot lines, bearings, curve data, easements Residential · Pacific Northwest3 markup rounds
Site plan conversionTopography traced from a PDF survey, legend rebuilt Residential · Tennessee1 day + 1 revision
Power and lighting planDesigner's markups drafted into the client's CAD Two-level residence · US4 days
Upper level ceiling planReflected ceiling with roof outline Two-level residence · US4 days
Salon suites test fitSchematic test fit inside a landlord's shell Tenant improvement · Florida2 revision rounds
Floor plan conversionTwo PDFs merged into one plan with rooms and dimensions Medical practice · Germany2 revision rounds
Custom home floor planPDF to DWG, re-layered to the builder's standard Homebuilder · US1–2 days
Front elevation from a sketchRoof pitches, materials, floor level Residential · US2 days
As-built elevationsAssumed sizes clouded for site check Residential · USWith basement and ground plans
Start
Send one sheet. See it by morning.
Send a PDF, sketch or markup with what you need. You get the question list and a fixed price before any work starts. Your first sheet is a $49 test: if it isn’t right, you don’t pay.
